1400 FOLDING House
1400H Export Folding Container House Technical Specification
| Basic Dimensions | |
|---|---|
| Expanded Dimensions | 5900mm(L) × 2480mm(W) × 2540mm(H) |
| Internal Dimensions | 5720mm(L) × 2360mm(W) × 2410mm(H) |
| Folded Dimensions | 5900mm(L) × 2480mm(W) × 340mm(H) |
| Component | Specifications | Material | Qty |
|---|---|---|---|
| Bottom Frame Purlin | Galvanized Square Tube 40×40×5.9M | Q235 Steel | 1 unit |
| Side Fan Main Beam | Galvanized Buckle Groove 5.9M | Q235 Steel | 4 units |
| Floor Panel | 2810×1180×18mm | Glass Magnesium Composite | 4 panels |
| Electrical Components | Specification | Rating |
|---|---|---|
| Main Wiring | 4mm² GB Soft Copper | - |
| Lighting Circuit | 2.5mm² GB Soft Copper | - |
| Grounding Wire | 1.5mm² GB Soft Copper | 8m length |
| Insulation System | Thickness | Density |
|---|---|---|
| Wall Panels | 65mm EPS | 12kg/m³ |
| Roof Insulation | 75mm Glass Wool | 14kg/m³ |
